51CH Hotel Room Control Host 2.0

model：MH48IP-II-HT.231

51CH Hotel Room Control Host 2.0 has 51 dry contacts, 2 RS485 expansion interfaces, 1 Buspro bus interface and 1 UDP network communication interface. The device can control doorbell panels, curtains, lights, fans, air conditioners, floor heating and other devices

51CH  Hotel Room Control Host 2.0 has 51 dry contacts, 2 RS485 expansion interfaces, 1 Buspro bus interface and 1 UDP network communication interface. The device can control doorbell panels, curtains, lights, fans, air conditioners, floor heating and other devices

■Through RJ45 port, UDP network communication is adopted, so that rooms, hotel room management software, debugging software and hotel property management system are interconnected, and information such as hotel room check-in, check-out and service is realized.
■Two RS485 interfaces, one RS485 interface is used for docking of third-party devices; the other Link interface supports HDL Inner Bus control.
■Buspro interface, supports HDL Buspro standard control.
■The device has 48 common channels, which can be used to control relays and dimmers.
■Two modes are available: card-free power-taking and card-inserting power-taking
■Supports up to 8 air conditioners, 8 curtain motors, 4 fans, and 3 floor heating devices. The control status of air conditioners, curtains, lamps and other equipment can be synchronized to various control terminals.
■51 dry contacts, support multiple mode selection and input and output settings.
■Personalized doorbell control methods are available.
■Supports 50 scenes, each scene can be configured with 32 targets.
■48 general logics and 8 normally used fixed logics.
■Supports system time setting.
■Saves the last history record.
Dimensions (W X H X D) : 72mm×90mm×67.5mm (see Figure 5 & 6)
Net weight: 130g
Housing material: Nylon, PC
Installation: 35mm DIN rail installation
Protection rating (Compliant with EN 60529): IP20
